The Groz Hydraulic Bottle Jacks lift, push, spread, bend, press, and straighten heavy loads. These jacks come with a "Load Limiting Device", a safety feature that ensures that the jack is not accidentally used beyond the rated capacity. These jacks are commonly used for DIY tire changes.
Manufactured from hardened and polished stainless steel, these jacks are welded to be leak-proof. The forged steel base plate imparts higher stability even under high load as compared to jacks with CI base plates. These jacks have a 50% safety overload factor.
The internally machined oil passages, smooth bearing surfaces, and close tolerances provide high durability. Machined and polished RAM with die cut threads reduce wear and tear. The powder coated 2 piece lifting lever rod with pressed ends provides convenient opening & closing of pressure release valve.
These jacks have a knurled heat-treated saddle head with non-slip surface, providing a stronger grip. All capacities conform to ASME, GS, and CE safety standards.
Specifications by Capacity
| Capacity | Lift Range | Recommended For Use With |
|---|---|---|
| 4 Ton (3,629 kg) | 7-7/16" - 14-13/16" (190-368mm) | Passenger cars, taxis, pick-up trucks, SUVs, MUVs, vans, LCVs, mini trucks |
| 12 Ton (10,886 kg) | 9-1/16" - 18-5/16" (230-465mm) | HCV, trucks (9-24 ton), buses |
| 20 Ton (18,144 kg) | 9-7/16" - 17-11/16" (240-450mm) | HCV, trucks (24-40 ton) |
| 32 Ton (29,030 kg) | 10-5/16" - 16-9/16" (260-420mm) | Trailers, dumpers (40-60 ton), RVs |
| 50 Ton (45,359 kg) | 11" - 17-11/16" (280-450mm) | Dumpers (60-120 ton) |
All capacities conform to ASME, GS, and CE safety standards.
The Groz Hydraulic Bottle Jacks lift, push, spread, bend, press, and straighten heavy loads. These jacks come with a "Load Limiting Device", a safety feature that ensures that the jack is not accidentally used beyond the rated capacity. These jacks are commonly used for DIY tire changes.
Manufactured from hardened and polished stainless steel, these jacks are welded to be leak-proof. The forged steel base plate imparts higher stability even under high load as compared to jacks with CI base plates. These jacks have a 50% safety overload factor.
The internally machined oil passages, smooth bearing surfaces, and close tolerances provide high durability. Machined and polished RAM with die cut threads reduce wear and tear. The powder coated 2 piece lifting lever rod with pressed ends provides convenient opening & closing of pressure release valve.
These jacks have a knurled heat-treated saddle head with non-slip surface, providing a stronger grip. All capacities conform to ASME, GS, and CE safety standards.
Specifications by Capacity
| Capacity | Lift Range | Recommended For Use With |
|---|---|---|
| 4 Ton (3,629 kg) | 7-7/16" - 14-13/16" (190-368mm) | Passenger cars, taxis, pick-up trucks, SUVs, MUVs, vans, LCVs, mini trucks |
| 12 Ton (10,886 kg) | 9-1/16" - 18-5/16" (230-465mm) | HCV, trucks (9-24 ton), buses |
| 20 Ton (18,144 kg) | 9-7/16" - 17-11/16" (240-450mm) | HCV, trucks (24-40 ton) |
| 32 Ton (29,030 kg) | 10-5/16" - 16-9/16" (260-420mm) | Trailers, dumpers (40-60 ton), RVs |
| 50 Ton (45,359 kg) | 11" - 17-11/16" (280-450mm) | Dumpers (60-120 ton) |
All capacities conform to ASME, GS, and CE safety standards.
